Hardware Installation
Figure 3-2. Mounting Bracket Option Code B4
Dimensions are in inches (millimeters).
Pipe mounting Panel mounting
2-in. U-Bolt
for pipe mounting
(clamp shown)
¼ × 1¼ Bolt
for transmitter mounting
(not supplies) 1.42 (36)
5.97 (152)
¼ × 1¼ Bolt
for transmitter mounting
(not supplies) 1.42 (36)
× 1½ Bolt
for panel mounting
(not supplies)
5
⁄
16
2.97
(75)
8.090
(205.5)
4.78
(121)
2.810
71.4
