REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 28
December 01/2010
Graphic
Balance gears, balance shaft
Figure 17
K00018, K00105
Part Function
1 Balance gears
2O-ring
3Groove
1
3
M11
1
2
M10
