DK00027.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 30
December 01/2010
Graphic
Crankcase
Figure 18
K00037
Part Function
1 Case halves
2 Sealing surfaces
3Thread
4 Main bearing lubrication hole
1
4
4
3
2
