Rotax 125 Micro MAX User Manual

DK00027.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 33
December 01/2010
Graphic Ignition end case half
10 Grease the installed oil seal for shaft with MOLYCOTE 111.
11 Press in the second oil seal for shaft to the limit stop with the installation tool
(8) (part no. 676021) so the open end of the oil seal for shaft is visible.
12 Allow the crankcase halves to cool in this position.
Step Procedure
2
3
1
4
6
5
8
7
