DK00027.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 35
December 01/2010
5.2) Assembly of crankshaft, water pump shaft and balance shaft
Safety
instructions
Special tools The following special tools and equipment are required:
Instructions See Figure 21.
Heat both crankcase halves with the bearings with and oil seal for shaft to
approx. 50 °C in the convection oven.
Ignition end case half
WARNING
WARNING
Danger of serious burns and scalding!
Wear safety gloves!
Part number Description Use
n.e Convection oven Case half
Part no. 297434 LOCTITE Anti-Seize Balance shaft, crankshaft
Step Procedure
1 Remove case half from the convection oven and drop onto a flat wood board
with the case split pane.
2 Coat main bearing seats of the crankshaft with LOCTITE Anti-Seize.
3 Insert the crankshaft (1) into the ignition end crankcase half to the limit stop.
4 Coat bearing seats of the balance shaft with LOCTITE Anti-Seize.
5 Insert the balance shaft (2) into the ignition end crankcase half to the limit stop.
6 Insert the water pump shaft (3) into the ignition end crankcase half to the limit
stop.
7 Position new gasket (4) on the ignition end crankcase half.
NOTES: Adjustment of the clearance of the crankshaft is not re-
quired.
