Rotax 125 Micro MAX User Manual

DK00027.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 41
December 01/2010
Crankcase
Figure 23
K00106, K00067, K00107
Part Function
1 O-ring 18x3.5
2 Balance gear
3 Balance shaft drive gear
4,5 Marking
6 Drive gear
7 Seeger ring AV 20
8 Thrust washer 10.1/17/1
9 Needle pin 4x15.8
10 Water pump pinion 16 Z
11 Idle gear
12 Gasket
13 Gearbox cover
14 Cyl. screw M6x25
15 Cyl. screw M6x30
14
15
14
14
15
14
14
14
13
