REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 6
Page 14
December 01/2010
Graphic
Intake silencer
Figure 8
K00063
Part Function
1 Intake silencer case, bottom
2 Intake silencer case, top
3 Intake silencer tube
4 Carburetor socket
5 Filter element
6 Support bracket
1
2
3
6
4
5
