Rotax 125 Micro MAX - Chapter 8: WATER RADIATOR; Water Radiator System Description; Removing the Water Radiator; Water Radiator Component Inspection

DK00030.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 8
Page 1
December 01/2010
Chapter: 8
WATER RADIATOR
Contents This chapter describes the removal and installation of the water radiator
module of the ROTAX 125 MAX engine. The description is divided into
sections.
Subject Page
System description Page 3
Removing the water radiator
Removal of the cooling water hose
Page 5
Page 5
Water radiator -inspection of components Page 7
Installation of water radiator
Installation of the cooling water hose
Installation of the water radiator
Page 9
Page 9
Page 10
