REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 4
Page 7
December 01/2010
Graphic
Cylinder
Part Function
1 M8 locknuts
2 Cylinder
3 Cylinder base gasket
4 Cylinder head cover
5 Cyl. screw M6x16
6 O-ring 105x2.5
7 Coolant thermostat
8 Taptite screw M4x8
9 Thermostat retaining bracket
10 Thermostat holder
11 Compression spring
12 Combustion chamber insert
13 Hex screw M8x30
2
15
12
16
6
5
14
1
3
13
4
7
11
9
8
10
