DK00026.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 4
Page 32
December 01/2010
Graphic
reed valve and carburetor flange
Figure 22
K00025
Part Function
1 Reed petal
2 Valve detent
3 Oval head screw M3x6
4 Gasket
5 Cylinder
6 Reed valve
7 Carburetor flange
8 Cyl. screw M6x25
5
1
2
4
6
7
8
3
