DK00027.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 10
December 01/2010
3.2) Removing bearing and oil seal for shaft
Safety
instructions
Special tools The following special tools and equipment are required:
Instructions See Figure 5.
Danger of serious burns and scalding!
Wear safety gloves!
Part number Description Use
n.e Convection oven Case halves
Part no. 676030 Installation tool Needle bearing
Step Procedure
1 Remove oil seal (1) and (2) from the two halves with suitable tools.
2 Remove oil seals (3) from water pump with suitable tools.
3 Remove pick up (4) for the ignition system by removing the two cyl. screws (5).
4 Remove air vent screw (6).
5 Remove countersunk screw (7) and thrust washer (8).
6 Heat the two halves of the case to approx. 150 °C in the convection oven until
the bearing can be tapped gently out.
