Operating Instructions Cubis
®
MCE 17
Device Description
3.6 Connections on the Control Unit
1
Fig. 7: Connections on the control unit
Pos. Name Description
1 USB connection Concealed, no function, for Sartorius Service only
3.7 Safety Equipment
3.7.1 Protective Caps on the Analytical Balance and Precision Balance
1 2 3 4 5
Fig. 8: Protective caps on the weighing module for the analytical balance and precision balance
Pos. Name Description
1 Protective cap for USB-A connection Plastic attachment hood, fastened to the device.
2 Protective cap for USB-B connection Plastic attachment hood, fastened to the device.
3 Protective cap for COM-RS232 connection Removable plastic sealing cap.
4 Protective cap for access switch Removable plastic sealing cap.
5 Protective cap for peripheral connection Removable plastic sealing cap.
