20 Operating Instructions Cubis
®
MCE
Operating Concept
4 Operating Concept
4.1 Operating Display in Weighing Mode
21
3
5
4
6
Fig. 1: Operating display in weighing mode (example)
Pos. Name Description
1 Symbols for the selected application
2 Weight value display In the selected basic unit.
3 Metrological data
4 Weight units Shows the selected basic unit, e.g. grams, [g].
5 Visual touch-feedback Visual note on an active button or key.
6 Operating and display area
