24 Operating Instructions Cubis
®
MCE
Operating Concept
Symbol Name Description
[Quantity] Indicates that a quantity is being displayed.
[Invalid weight value] display − Indicates that the display does not contain a weight value, rather it
is the calculated result of an application, e.g. for the “Totalizing”
application.
− For conformity-assessed devices: Indicates a fault. The cause of
this fault is displayed after pressing the [Change] key.
[Directional arrows] display If leveling with the inclination sensor is active: Displays the direction
of rotation of the leveling foot.
4.5 Menu Structure
4.5.1 Overview of the Device Settings Menu
t Navigating in Menus (see Chapter 4.6, page 29).
Level 1 Level 2 Level 3 Description
SETUP BALANCE AMBIENT
“Ambient conditions”
Enter the ambient conditions at the device’s
installation site.
APP FILT.
“Application filter”
− Equalize the load deviations in the display.
− The load deviations occur between the complete
placement of the sample on the weighing pan and
reaching the final result display.
STABIL.
“Stability range”
− Define the accuracy of the stability range.
− If the weight unit symbol appears, the weight
readout is stable within the range indicated by the
stability range
ST.DEL.
“Stability delay”
− Define the duration of the stability delay.
− The stability delay is used to bridge residual
fluctuations in the vibration of the device in order
to display reliable results.
ZERO/TAR.
“Zeroing and taring”
Define the trigger for zeroing and taring.
AUTOZER.
“Auto zero”
− Activate | deactivate automatic control of the zero
display.
− The deviations of a set fraction of scale intervals
per second starting from the display zero point are
automatically zeroed.
UNIT − Define the weight unit, e.g. grams, kilograms,
pounds.
− Depending on the country-specific model version,
not all weight units listed may be available.
− Some weight units may be blocked from use in
conformity-assessed devices, depending on
national verification laws.
