Operating Instructions Cubis
®
MCE 69
Cleaning and Maintenance
9 Cleaning and Maintenance
9.1 Preparing a Device with an Analytical Draft
Shield or Flat Glass Draft Shield
Procedure
t Turn the device off.
t Disconnect the device from the power supply. To do so, disconnect the
power supply cable from the wall outlet.
t Fully open the draft shield side panels and upper panel.
t Remove the weighing pan and all associated components from the
weighing compartment, e.g. shield plate, pan support.
t To remove the side panels:
t If this relates to a device with an analytical draft shield: Press and hold
the locking button (1) on the door handle and pull the side panels
completely out of the guide rails.
1
