Date Code 20010731 Installation 2-1
SEL-352-1, -2 Instruction Manual
SECTION 2: INSTALLATION
Design your installation using the mounting and connection information in this section. Options
include rack or panel mounting and terminal block or plug-in connector (Connectorized
®
) wiring.
This section also includes information on configuring the relay for your application.
RELAY MOUNTING
Rack Mount
We offer the SEL-352 Relay in a rack-mount version that bolts easily into a standard 19-inch
rack. See Figure 2.2 and Figure 2.3. From the front of the relay, insert four bolts (two on each
side) through the holes on the relay mounting flanges, and use nuts to secure the relay to the
rack. See Figure 2.1.
Panel Mount
We also offer the SEL-352 Relay in a panel-mount version for a clean look. Panel-mount relays
have sculpted front-panel molding that covers all installation holes. See Figure 2.4 and
Figure 2.5. Cut your panel and drill mounting holes according to the dimensions in Figure 2.1.
Insert the relay into the cutout, aligning four relay mounting studs on the rear of the relay with
the drilled holes in your panel, and use nuts to secure the relay to the panel.
