Date Code 20010731 Distributed Network Protocol (DNP) 3.00 G-13
SEL-352-1, -2 Instruction Manual
Analog Outputs (objects 40 and 41) are supported as defined by the preceding table. Flags
returned with object 40 responses are always set to 0. The Control Status field of object 41
requests is ignored. If the value written to index 0 is outside of the range 1 through 6, the relay
will not accept the value and will return a hardware error status.
Table G.4: SEL-352-2 Relay Binary Input Lookup Table
Row SEL-352 Relay Word Bits
Binary
Input
Point
General Elements
2 Y59L3 X59L3 50LDC 50LDB 50LDA 50FTC 50FTB 50FTA 7–0
3 87THA 87FOA Y27D3 X27D3 50N 50MDC 50MDB 50MDA 15–8
4 47Q 37OP 25T 46P 87THC 87FOC 87THB 87FOB
23–16
5 X59LC X59HC X27DB X59LB X59HB X27DA X59LA X59HA 31–24
6 ZERO Y27DC Y59LC Y27DB Y59LB Y27DA Y59LA X27DC 39–32
7 ONE 50MNC 50MNB 50MNA 87F 87H 87TH X59H
47–40
8 25M 25C 46C 46B 46A 50MD 50LD 50FT 55–48
9 Y47Q X47Q 37OPC 37OPB 37OPA 87HC 87HB 87HA 63–56
10 CCMD TCMD XNTC XPTC XNTB XPTB XNTA XPTA 71–64
11 * * YNTC YPTC YNTB YPTB YNTA YPTA 79–72
12 RB8 RB7 RB6 RB5 RB4 RB3 RB2 RB1 87–80
13 RB16 RB15 RB14 RB13 RB12 RB11 RB10 RB9 95–88
14 LB8 LB7 LB6 LB5 LB4 LB3 LB2 LB1 103–96
15 LB16 LB15 LB14 LB13 LB12 LB11 LB10 LB9 111–104
16 * * * BCW 50R 50RC 50RB 50RA 119–112
17 * * IN106 IN105 IN104 IN103 IN102 IN101 127–120
18 IN208 IN207 IN206 IN205 IN204 IN203 IN202 IN201 135–128
19 IN216 IN215 IN214 IN213 IN212 IN211 IN210 IN209 143–136
20 IN308 IN307 IN306 IN305 IN304 IN303 IN302 IN301 151–144
21 IN316 IN315 IN314 IN313 IN312 IN311 IN310 IN309 159–152
22 MCLOSE CLOSE TRIP3 TRIPC TRIPB TRIPA SS2 SS1 167–160
23 * LODCT LOD2 LOD1 MODST 52AC 52AB 52AA 175–168
SELOGIC
®
Control Equation SET A Elements
24 L1CR L1CS L1BQ L1BR L1BS L1AQ L1AR L1AS 183–176
25 * T1CD T1C T1BD T1B T1AD T1A L1CQ 191–184
26 * * * * * SAC SAB SAA 199–192
Fault Current Protection Elements
27 LFAR LFAS TTCD TTC TTBD TTB TTAD TTA 207–200
28 * LFCQ LFCR LFCS LFBQ LFBR LFBS LFAQ 215–208
29 * * FCCD FCC FCBD FCB FCAD FCA 223–216
