Date Code 20010731 Command Summary 1
SEL-352-1, -2 Instruction Manual
SEL-352-1, -2 RELAY COMMAND SUMMARY
ASCII
Command
Command Description
Minimum
Access
Level
Front-
Panel
Equivalent
2AC
ACC
BAC
Enter Access Level 2, 1, or B. Install main board password
jumper JMP6A to disable password protection.
1, B
0
1
Relay
prompts if
necessary
BRE
BRE C
BRE R
BRE S
BRE W
Display detailed breaker pole operations, summary, and alarms.
Clear breaker pole operations, operation summary, and alarms.
Clear breaker pole operations, operation summary, and alarms
(SEL-352-2 Relay only).
Display only breaker operation summary and alarms.
Preload breaker wear data (SEL-352-2 Relay only).
1
2
2
1
B
EVENTS
CAL Enter the calibration access level. 2
CEVE Display compressed version of EVE for SEL-5601 software. 1
CLO Assert the CCMD bit for 30 cycles. JMP6B must be in place. B CNTRL
CON n Control Remote Bit RBn. 2
COP m n Copy settings from group m (1, 2, or 3) to group n (1, 2, or 3). 2
DAT
DAT d1
Display relay date according to the format setting DATE_F.
Set relay date to d1. If the date format setting DATE_F = MDY,
d1 is m/d/y. If DATE_F = YMD, d1 is y/m/d.
1 OTHER
EVE
n
A
Ss
Lc
Display an event report with VX and I channels.
n specifies event number according to the HIS command.
A specifies the alternate report showing VY (not VX and I).
Ss specifies the samples per cycle (s = 4, 8, 16, 64).
Lc specifies the length in cycles (c = 1 to LER setting).
Unspecified options are n = 1, no A, s = 4, and c = LER.
1
GRO
GRO n
Display the active setting group number and group variable.
Change the group variable to n (n = 1, 2, or 3).
1
2
GROUP
GROUP
HEA k
HEA C
HEA R
Display the energy in the trip and close resistors k times.
Reset the thermal model to zero.
Reset the thermal model to zero.
1
2
2
HIS n
HIS C
Show the summaries of the n latest events.
Clear all of the summaries and corresponding events.
1
2
EVENTS
INI Initialize and display the inputs and outputs per I/O board. 1
IRI Attempt IRIG-B time-code input synchronization. The relay
attempts synchronization automatically every minute.
1
MET k Display metering data k times. 1 METER
OPE Assert the TCMD bit for 30 cycles. JMP6B must be in place. B CNTRL
