R ELAY W ORD B ITS
The Relay Word bits available for use in SEL OGIC control equations (except Row 0 or Row 1
target elements) are listed below in
Table 4.8 through Table 4.10. Table 4.8 shows the names
and locations in each row. The row number or bit name can be used when using the TAR
command.
Table 4.9 lists the Relay Word bit definitions, in their row order. Table 4.10 lists the
Relay Word bits alphabetically, to provide an easier method for looking for a specific bit.
Table 4.8: SEL-387E Relay Word Bits and Locations
Row SEL-387E Relay Word Bits
0 EN TRIP INST 87-1 87-2 87-3 24 81
1 A B C N W1 W2 W3 50/51
2 50P11 50P11T 50P12 51P1 51P1T 51P1R PDEM1 OCA
3 50A13 50B13 50C13 50P13 50A14 50B14 50C14 50P14
4 50N11 50N11T 50N12 51N1 51N1T 51N1R NDEM1 OC1
5 50Q11 50Q11T 50Q12 51Q1 51Q1T 51Q1R QDEM1 CC1
6 50P21 50P21T 50P22 51P2 51P2T 51P2R PDEM2 OCB
7 50A23 50B23 50C23 50P23 50A24 50B24 50C24 50P24
8 50N21 50N21T 50N22 51N2 51N2T 51N2R NDEM2 OC2
9 50Q21 50Q21T 50Q22 51Q2 51Q2T 51Q2R QDEM2 CC2
10 50P31 50P31T 50P32 51P3 51P3T 51P3R PDEM3 OCC
11 50A33 50B33 50C33 50P33 50A34 50B34 50C34 50P34
12 50N31 50N31T 50N32 51N3 51N3T 51N3R NDEM3 OC3
13 50Q31 50Q31T 50Q32 51Q3 51Q3T 51Q3R QDEM3 CC3
14 * 27V1 27PP2 27PP1 27P2 27P1 * CTS
15 59Q 59G2 59G1 59V1 59PP2 59PP1 59P2 59P1
16 81D1 81D2 81D3 81D4 81D5 81D6 ISQTAL 27B81
17 81D1T 81D2T 81D3T 81D4T 81D5T 81D6T * *
18 87U1 87U2 87U3 87U 87R1 87R2 87R3 87R
19 2HB1 2HB2 2HB3 5HB1 5HB2 5HB3 TH5 TH5T
20 87BL1 87BL2 87BL3 87BL 87E1 87E2 87E3 32IE
21 87O1 87O2 87O3 24D1 24D1T 24C2 24C2T 24CR
22 51PC1 51PC1T 51PC1R 51NC1 51NC1T 51NC1R DC1 DC2
23 * * * * * * DC3 DC4
24 RB1 RB2 RB3 RB4 RB5 RB6 RB7 RB8
25 RB9 RB10 RB11 RB12 RB13 RB14 RB15 RB16
26 SG1 SG2 SG3 SG4 SG5 SG6 CHSG *
27 4HBL DCBL IN106 IN105 IN104 IN103 IN102 IN101
28** IN208 IN207 IN206 IN205 IN204 IN203 IN202 IN201
29** IN216 IN215 IN214 IN213 IN212 IN211 IN210 IN209
30 * * * * * * * *
31 * * * * * * * *
32 S1V1 S1V2 S1V3 S1V4 S1V1T S1V2T S1V3T S1V4T
33 S2V1 S2V2 S2V3 S2V4 S2V1T S2V2T S2V3T S2V4T
