Table 8.2: Correspondence Between Local Control Switch Types
and Required Label Settings
Local Switch Type Label NLBn Label CLBn Label SLBn Label PLBn
ON/OFF X X X
OFF/MOMENTARY X X X
ON/OFF/MOMENTARY X X X X
Disable local control switches by “nulling out” all the label settings for that switch. The local bit
associated with this disabled local control switch is then fixed at logical 0.
Factory Settings Examples
Local bits LB3 and LB4 are used in a few of the factory SEL OGIC control equation settings for
manual trip and close functions. Their corresponding local control switch position labels are set
to configure the switches as OFF/MOMENTARY switches:
Local Bit
Label Settings Function
LB3 NLB3 = MANUAL TRIP 1 trips breaker and drives reclosing relay to
lockout
CLB3 = RETURN OFF position (“return” from MOMENTARY
position)
SLB3 = ON position – not used (left “blank”)
PLB3 = TRIP MOMENTARY position
LB4 NLB4 = MANUAL CLOSE 1 closes breaker, separate from automatic
reclosing
CLB4 = RETURN OFF position (“return” from MOMENTARY
position)
SLB4 = ON position – not used (left “blank”)
PLB3 = CLOSE MOMENTARY position
View Local Control (With Factory Settings)
Access local control via the CNTRL pushbutton. If local control switches exist (i.e.,
corresponding switch position label settings were made), the following message displays with
the rotating default display messages.
Press CNTRL for
Local Control
Press the CNTRL pushbutton, and the first set local control switch displays (shown here with
factory default settings).
