Schweitzer Engineering Laboratories SEL-387E - CEVENT Differential Report; CEVENT Winding Report (Default

E-6 Compressed ASCII Commands Date Code 20080110
SEL-387E Instruction Manual
CEVENT Winding Report (Default)
If DIF is not specified in the command line, the default report is the winding currents report. To
obtain a report, send the following:
CEV <Enter>
The relay responds:
<STX>
"FID","yyyy"<CR>
"FID=SEL-387E-XXXX-V-ZXXXXXX-DXXXXXXXX","yyyy"<CR>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"FREQ","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC","EVENT","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,"xxxx","yyyy"<CR>
"IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","VAWX",
"VBWX","VCWX","VDC","TRIG","FREQ","DIGITAL_ELEMENT_NAMES","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,"z","RLY_BITS"<CR>
... (previous line repeated for SAM/CYC_A*NUM_OF_CYC)
"SETTINGS","yyyy"<CR>
"SETTINGS text","yyyy"<CR>
<ETX>
Note: "DIGITAL_ELEMENT_NAMES" consists of the text strings representing the names for
the relay word bits from the element store visible to the user, excluding the first 2 front-
panel rows.
Where:
xxxx are the data values corresponding to the first line labels.
yyyy is the 4-byte ASCII representation of the hex checksum for the line.
z is ">" to mark where the event was triggered, "*" to mark the maximum current
for the event, with the "*" overriding the ">"
RLY_BITS relay element data, in hex ASCII, corresponding to the
DIGITAL_ELEMENT_NAMES
SETTINGS text refers to the current settings of the relay as described in the event report
section.
Note: If the analog current input names (IAW1, etc.) have been changed via the Analog Input
Labels global settings, they will appear in the above report as set.
CEVENT Differential Report
If DIF is specified in the command line, the report on differential element quantities is provided.
To obtain the report, send the following:
CEV DIF <Enter>
