7-2 Communications Date Code 20080110
SEL-387E Instruction Manual
SEL Part No. Length Description
240-1575 15 M 15 M Duplex Fiber Cable LC/LC
240-1520 1 M Shielded CAT 5 Patch Cable RJ-45/RJ-45
240-1521 5 M Shielded CAT 5 Patch Cable RJ-45/RJ-45
240-1523 15 M Shielded CAT Patch Cable RJ-45/RJ-45
S
ERIAL
P
ORT
I
NTERFACES
Terminal Software
You can use a variety of terminal emulation programs on your personal computer to
communicate with the relay. Examples of PC-based terminal emulation programs include the
following:
• CROSSTALK
®
• Microsoft
®
Windows
®
Terminal and HyperTerminal
®
• ProComm Plus
®
• Relay Gold
®
• SmartCOM
®
For the best display, use VT-100 terminal emulation or the closest variation. The default settings
for all serial ports are:
Baud Rate = 2400
Data Bits = 8
Parity = N
Stop Bits = 1
To change the port settings, use the SET P <Enter> command (see Section 6: Settings) or the
front-panel SET pushbutton (see Section 8: Front-Panel Operations).
Communications Devices
Devices useful for communications include the following:
• SEL-2032, SEL-2030, and SEL-2020 Communications Processors
• SEL-2600A RTD Modules
