6-16 Settings Date Code 20080110
SEL-387E Instruction Manual
(continued from previous page)
OUT208 =0
OUT209 =0
OUT210 =0
OUT211 =0
OUT212 =0
SCEUSE 47.8
GR1CHK 6804
=>>
Note: SCEUSE is the percent of SEL
OGIC
control equations used in this setting group.
GRnCHK is the Group setting checksum used by the relay's diagnostics.
The Group settings shown above are the only settings which are different from the 5 A relay
settings. The Global, Port, and SER settings remain the same.
S
ETTINGS
S
HEETS
The following Settings Sheets may be photocopied, filled out, and used as reference when you
are entering settings. Refer to Section 1: Introduction and Specifications for information on
5 A nominal and 1 A nominal ordering options and how they influence overcurrent element
setting ranges and accuracies.
