Date Code 20080110 Firmware and Manual Versions A-5
SEL-387E Instruction Manual
E THERNET P ORT F IRMWARE
Table A.2 lists the Ethernet port firmware versions, a description of modifications, and the
instruction manual date code that corresponds to firmware versions. The most recent firmware
version is listed first.
Note: This information only applies to relays equipped with optional Ethernet ports.
Table A.2: Ethernet Port Firmware Revision History
Firmware
Identification (FID) Number Description of Changes
Manual
Date Code
This firmware differs from the previous version as follows:
SEL-E3-R104-V0-Z001001-D20080110 − Enhanced IEC 61850 functionality with KEMA certification
updates.
− Made improvements to IEC 61850 control operation priorities
when using IEC 61850 GOOSE messaging.
− Improved CID parse failure notification for the STA and ID
commands.
20080110
SEL-E3-R102-V0-Z001001-D20060814
− Initial release. 20060801
Newer Ethernet port firmware (R104 and higher) uses a different software library from earlier
versions and is unable to process version 001 CID files.
AC SEL ERATOR
®
Architect
™
SEL-5032
Software generates CID files from ICD files so the ICD file version number and CID file version
number are the same. If downloaded to the Ethernet port, an incompatible CID file will generate
file parse errors during processing and disable the IEC 61850 protocol.
If you perform an Ethernet port firmware upgrade that spans different file version
compatibilities, the relay may not be able to process the stored CID file. See Ethernet Port
Firmware Upgrade Instructions in Appendix B: SEL-300 Series Firmware Upgrade
Instructions for CID file conversion procedures.
See
Table A.3 for compatibilities between AC SEL ERATOR Architect, ICD/CID file, and Ethernet
port firmware versions.
Table A.3:
AC SEL ERATOR Architect CID File Compatibility
AC SEL ERATOR Architect
Software Version
AC SEL ERATOR Architect
ICD/CID File Version
Ethernet Port
Firmware
All versions Ver 001 R102
R.1.1.69.0 or later
Ver 002/002L R104 or later
