Date Code 20080110 Settings 6-1
SEL-387E Instruction Manual
SECTION 6: SETTINGS
I
NTRODUCTION
Change or view settings with the SET and SHOWSET serial port commands and the front-panel
SET pushbutton.
Table 6.1 lists the serial port SET commands.
Table 6.1: Serial Port SET Commands
Command
Settings
Type
Description
SET n Relay Overcurrent elements for Settings Group n (n = 1, 2, 3, 4, 5, 6).
SET G Global Battery and breaker monitor, analog input label, setting group
control, programmable LED, display point, and local control
switch settings.
SET R SER Sequential Events Recorder trigger condition settings.
SET P n Port Serial port settings for Serial Port n (n = 1, 2, 3, or 4). The
Ethernet port, if available, is designated as Port 5 or Port 6
(note that Port 6 is not available at this time).
View settings with the respective serial port SHOWSET commands (SHO, SHO G, SHO R,
SHO P). See discussion of SHO commands in Section 7: Communications. Settings Sheets are
located at the end of this section.
S
ETTINGS
C
HANGES VIA THE
F
RONT
P
ANEL
The relay front-panel SET pushbutton provides access to the Relay, Global, and Port settings
only. Thus, the corresponding Relay, Global, and Port settings sheets that follow in this section
can also be used when making these settings via the front panel. Refer to Figure 8.9 in
Section 8: Front-Panel Operation for information on front-panel settings.
S
ETTINGS
C
HANGES VIA THE
S
ERIAL
P
ORT
Note: In this manual commands you type appear in bold/upper case: SHOWSET. You need
to type only the first three letters of a command, for example, SHO. Computer keys you
press appear in bold/upper case/brackets: <Enter>.
See Section 7: Communications for information on serial port communications and relay access
levels. The SET commands in
Table 6.1 operate at Access Level 2 (screen prompt: =>>). To
change a specific setting, enter the command:
SET n m s TERSE
