7-42 Communications Date Code 20080110
SEL-387E Instruction Manual
• iedName: the IED name (e.g., SEL_387E_OtterTail)
• type: the IED type (e.g., SEL_387E)
• configVersion: the CID file configuration version
(e.g., ICD-387E-R100-V0-Z001001-D20060512)
MAC
Access Level 1, 2
Use the MAC command to display the MAC address of PORT 5 and PORT 6, as shown below.
Port 5 MAC Address: 00-30-A7-00-00-00
Port 6 MAC Address: 00-30-A7-23-23-23
QUI
Access Levels 0, 1, 2
Enter QUIT over Telnet on an optional Ethernet port to return the relay to Access Level 0 on
that port.
STA
STA
Access Level 1, 2
Enter STA over Telnet on an optional Ethernet port to obtain a status report for the Ethernet port.
Items in the STA report are the header, failures, warnings, Ethernet link status, and
communications card operational status.
The self-test status fields shown below are the same as those shown at the bottom of a STA
report obtained using a serial port, with the exceptions of CR_RAM and NON_VOL. The
CR_RAM and NON_VOL fields are combined with the ROM field in the serial port STA report.
When CR_RAM is FAIL then there is a failure in the nonvolatile Ethernet port configuration.
When NON_VOL is FAIL then there is a failure with the nonvolatile CID file. The other fields
are defined in the Relay Command Explanations section.
Date: 04/24/2006 Time: 16:54:22
FID = SEL-E3-R100-V0-Z001001-D20060616 CID = 78E5
HOST PORT 5 PORT 6 RAM ROM FPGA DPRAM CR_RAM NON_VOL PS
OK LINK NOLINK OK OK OK OK OK OK OK
Device Enabled
