Date Code 20080110 Distributed Network Protocol (DNP3) G-21
SEL-387E Instruction Manual
SEL-387E R
ELAY
DNP P
ORT
—SET P S
ETTINGS
S
HEET
Port Protocol (SEL, LMD, DNP) PROTO = DNP
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED =
Port Time-out (0–30 minutes) T_OUT =
DNP Address (0–65534) DNPADR =
Modem connected to port (Y, N) MODEM =
Modem startup string (up to 30 characters) MSTR =
Phone number to dial-out to (up to 30 characters) PH_NUM =
Time to attempt dial (5–300 seconds) MDTIME =
Time between dial-out attempts (5–3600 seconds) MDRETI =
Number of dial-out attempts (0–5) MDRETN =
Class for Analog event data (0 for no event, 1–3) ECLASSA =
Class for Binary event data (0 for no event, 1–3) ECLASSB =
Class for Counter event data (0 for no event, 1–3) ECLASSC =
Currents scaling (0–3 decimal places) DECPLA =
Voltage scaling (0–3 decimal places) DECPLV =
Misc. scaling (0–3 decimal places) DECPLM =
Time-set request interval, minutes (0 for never, 1–32767) TIMERQ =
Select/Operate time-out interval, seconds (0.0–30.0) STIMEO =
Data link time-out interval, seconds (0–5) DTIMEO =
Minimum Delay from DCD to transmission, seconds
(0.00–1.00)
MINDLY
=
Maximum Delay from DCD to transmission, seconds
(0.00–1.00)
MAXDLY
=
Transmission delay from RTS assertion, seconds
(OFF, 0.00–30.00)
PREDLY
=
Post-transmit RTS deassertion delay, seconds
(0.00–30.00)
PSTDLY
=
Analog reporting dead band (0–32767 counts) ANADBA =
Analog reporting dead band (0–32767 counts) ANADBV =
Analog reporting dead band (0–32767 counts) ANADBM =
Event Data Confirmation time-out (0.1–50.0 sec) ETIMEO =
