Date Code 20080110 Communications 7-41
SEL-387E Instruction Manual
An example response to the GOOSE command is shown in Figure 7.3.
#>>GOO <Enter>
GOOSE Transmit Status
-----------------------------------------------------------------------------
SEL-387E_Line/LLN0$GO$GooseDSet13
2:5 1256 347 6
Data Set: SEL-387E_Line/LLN0$GooseDSet13
GOOSE Receive Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL-311L_Line_DifferentialCFG/LLN0$GO$GooseDSet13
01-03-A7-00-00-01 3:1 1253758689 4786543985 123456
Data Set: SEL-311L_Line_Differential/LLN0$GooseDSet13
SEL-387E_Current_DifferentialCFG/LLN0$GO$GooseDSet13
01-03-A7-00-00-01 3:23 12568945 34 0
Data Set: SEL-387E_1_CFG_Current_Differential/LLN0$GooseDSet13
SEL-421_DistanceCFG/LLN0$GO$GooseDSet13
01-03-A7-00-00-01 3:343 1945 34456 456
Data Set: SEL-421_Distance/LLN0$GooseDSet13
SEL-487B_Bus_DifferentialCFG/LLN0$GO$GooseDSet13
01-03-A7-00-00-01 3:5 12568945 34783456 123456
Data Set: SEL-487B_Bus_Differential/LLN0$GooseDSet13
#>>
Figure 7.3: GOOSE Command Response
HELP
Access Levels 1, 2
The HELP command gives a list of commands available at the present access level. You can
also get a description of any particular command; type HELP followed by the name of the
command for help on that command.
ID
Access Levels 0, 1, 2
Enter ID over Telnet on an optional Ethernet port to obtain Ethernet port identification and
configuration information.
Each line of the ID command report contains an identification code and a line checksum. The
SEL-387E presents these codes in the following order, but the optional iedName, type, and
configVersion codes will only be displayed if IEC 61850 is enabled (E61850 = Y). The optional
codes are taken from the IED element in the CID file and can be used to verify that the document
has the expected CID file.
• FID: the Firmware Identification string
• BFID: the Boot Firmware Identification string
• CID: the checksum of the firmware
