Date Code 20080110 Compressed ASCII Commands E-5
SEL-387E Instruction Manual
"POLE1","POLE2","POLE3","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC",
"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
<ETX>
where The data are a summation of breaker information collected since the last summary
clear.
xxxx are the data values corresponding to the first line labels.
yyyy is the 4-byte ASCII representation of the hex checksum for the line.
CEVENT C
OMMAND
The CEV report contains every analog and digital element found in an EVE report, and displays
the information in Compressed ASCII format by sending:
CEV [DIF R] [n Sx Ly[-[w]] C] <Enter>
The command parameters, all optional, can be entered in any order. They are:
Report Types:
DIF Display differential information for the all elements
R Displays raw (unfiltered) analog data and raw station battery
Displays preceding 1.5 cycles (including reports with ‘L’ options)
Allows S4, S8, S16, S32, and S64
Defaults to S16 samples/cycle
(default) Display cosine filtered fundamental currents on all windings and
station battery averaged for 1 cycle
Report Options:
n Event number
Default to 1
Sx Samples per cycle
x = 4 or 8 (See ‘R’ option)
Default to 4 if Sx not specified
Ly Display first y cycles of event report
y = 1 - LER
Default to L15 if Ly not specified
Ly- Displays event report from cycle y to end of report
Ly-w Displays event report from cycle y to cycle w
C Default to 8 samples/cycle (same as EVE C)
Note: If Sx and/or Ly are given, they override all other parameters.
Note: The L and U parameters are supported for consistency with the SEL-321 Relay.
The C parameter is used for SEL-2020 compatibility.
