Schweitzer Engineering Laboratories SEL-387E - Object Table

G-6 Distributed Network Protocol (DNP3) Date Code 20080110
SEL-387E Instruction Manual
Default Counter Object/Variation:
No Counters Reported
Configurable (attach explanation)
; Default object 20
Default variation 6
Point-by-point list attached
Counters Roll Over at:
No Counters Reported
Configurable (attach explanation)
; 16 Bits
32 Bits
Other Value
Point-by-point list attached
Sends Multi-Fragment Responses: ;Yes No
In all cases of a configurable item within the device profile, the item is controlled by SEL-387E
settings.
O BJECT T ABLE
The following object table lists supported objects, functions, and qualifier code combinations.
Table G.2: SEL-387E DNP Object Table
Object
Request
(supported)
Response
(may generate)
Obj.
*default
Var. Description
Function
Codes
(decimal)
Qualifier
Codes
(hex)
Function
Codes
(decimal)
Qualifier
Codes
(hex)
1 0 Binary Input–All Variations 1 0,1,6,7,8
1 1 Binary Input 1 0,1,6,7,8 129 0,1,7,8
1 2* Binary Input With Status 1 0,1,6,7,8 129 0,1,7,8
2 0 Binary Input Change–All Variations 1 6,7,8
2 1 Binary Input Change Without Time 1 6,7,8 129 17,28
2 2* Binary Input Change With Time 1 6,7,8 129,130 17,28
2 3 Binary Input Change With Relative Time 1 6,7,8 129 17,28
10 0 Binary Output–All Variations 1 0,1,6,7,8
10 1 Binary Output
10 2* Binary Output Status 1 0,1,6,7,8 129 0,1
12 0 Control Block–All Variations
12 1 Control Relay Output Block 3,4,5,6 17,28 129
echo of
request
12 2 Pattern Control Block
12 3 Pattern Mask
20 0 Binary Counter–All Variations 1 0,1,6,7,8
20 1 32-Bit Binary Counter
20 2 16-Bit Binary Counter
