Date Code 20080110 Distributed Network Protocol (DNP3) G-7
SEL-387E Instruction Manual
Object
Request
(supported)
Response
(may generate)
Obj.
*default
Var. Description
Function
Codes
(decimal)
Qualifier
Codes
(hex)
Function
Codes
(decimal)
Qualifier
Codes
(hex)
20 3 32-Bit Delta Counter
20 4 16-Bit Delta Counter
20 5 32-Bit Binary Counter Without Flag 1 0,1,6,7,8 129 0,1,7,8
20 6* 16-Bit Binary Counter Without Flag 1 0,1,6,7,8 129 0,1,7,8
20 7 32-Bit Delta Counter Without Flag
20 8 16-Bit Delta Counter Without Flag
21 0 Frozen Counter–All Variations
21 1 32-Bit Frozen Counter
21 2 16-Bit Frozen Counter
21 3 32-Bit Frozen Delta Counter
21 4 16-Bit Frozen Delta Counter
21 5 32-Bit Frozen Counter With Time of Freeze
21 6 16-Bit Frozen Counter With Time of Freeze
21 7 32-Bit Frozen Delta Counter With Time of Freeze
21 8 16-Bit Frozen Delta Counter With Time of Freeze
21 9 32-Bit Frozen Counter Without Flag
21 10 16-Bit Frozen Counter Without Flag
21 11 32-Bit Frozen Delta Counter Without Flag
21 12 16-Bit Frozen Delta Counter Without Flag
22 0 Counter Change Event–All Variations 1 6,7,8
22 1 32-Bit Counter Change Event Without Time 1 6,7,8 129 17,28
22 2* 16-Bit Counter Change Event Without Time 1 6,7,8 129,130 17,28
22 3 32-Bit Delta Counter Change Event Without Time
22 4 16-Bit Delta Counter Change Event Without Time
22 5 32-Bit Counter Change Event With Time 1 6,7,8 129 17,28
22 6 16-Bit Counter Change Event With Time 1 6,7,8 129 17,28
22 7 32-Bit Delta Counter Change Event With Time
22 8 16-Bit Delta Counter Change Event With Time
23 0 Frozen Counter Event–All Variations
23 1 32-Bit Frozen Counter Event Without Time
23 2 16-Bit Frozen Counter Event Without Time
23 3 32-Bit Frozen Delta Counter Event Without Time
23 4 16-Bit Frozen Delta Counter Event Without Time
23 5 32-Bit Frozen Counter Event With Time
