Schweitzer Engineering Laboratories SEL-387E - Through-Fault Event Monitor

G-8 Distributed Network Protocol (DNP3) Date Code 20080110
SEL-387E Instruction Manual
Object
Request
(supported)
Response
(may generate)
Obj.
*default
Var. Description
Function
Codes
(decimal)
Qualifier
Codes
(hex)
Function
Codes
(decimal)
Qualifier
Codes
(hex)
23 6 16-Bit Frozen Counter Event With Time
23 7 32-Bit Frozen Delta Counter Event With Time
23 8 16-Bit Frozen Delta Counter Event With Time
30 0 Analog Input–All Variations 1 0,1,6,7,8
30 1 32-Bit Analog Input 1 0,1,6,7,8 129 0,1,7,8
30 2 16-Bit Analog Input 1 0,1,6,7,8 129 0,1,7,8
30 3 32-Bit Analog Input Without Flag 1 0,1,6,7,8 129 0,1,7,8
30 4* 16-Bit Analog Input Without Flag 1 0,1,6,7,8 129 0,1,7,8
31 0 Frozen Analog Input–All Variations
31 1 32-Bit Frozen Analog Input
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of Freeze
31 4 16-Bit Frozen Analog Input With Time of Freeze
31 5 32-Bit Frozen Analog Input Without Flag
31 6 16-Bit Frozen Analog Input Without Flag
32 0 Analog Change Event–All Variations 1 6,7,8
32 1 32-Bit Analog Change Event Without Time 1 6,7,8 129 17,28
32 2* 16-Bit Analog Change Event Without Time 1 6,7,8 129,130 17,28
32 3 32-Bit Analog Change Event With Time 1 6,7,8 129 17,28
32 4 16-Bit Analog Change Event With Time 1 6,7,8 129 17,28
33 0 Frozen Analog Event–All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
40 0 Analog Output Status–All Variations 1 0,1,6,7,8
40 1 32-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
40 2* 16-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
41 0 Analog Output Block–All Variations
41 1 32-Bit Analog Output Block 3,4,5,6 17,28 129 echo of
request
41 2 16-Bit Analog Output Block 3,4,5,6 17,28 129
echo of
request
50 0 Time and Date–All Variations
