Schweitzer Engineering Laboratories SEL-387E - Page 515

Date Code 20080110 Distributed Network Protocol (DNP3) G-9
SEL-387E Instruction Manual
Object
Request
(supported)
Response
(may generate)
Obj.
*default
Var. Description
Function
Codes
(decimal)
Qualifier
Codes
(hex)
Function
Codes
(decimal)
Qualifier
Codes
(hex)
50 1 Time and Date 1,2
7,8
index = 0
129
07,
quantity=1
50 2 Time and Date With Interval
51 0 Time and Date CTO–All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO
07,
quantity=1
52 0 Time Delay–All Variations
52 1 Time Delay Coarse
52 2 Time Delay Fine 129
07,
quantity=1
60 0 All Classes of Data 1,20,21 6
60 1 Class 0 Data 1 6
60 2 Class 1 Data 1,20,21 6,7,8
60 3 Class 2 Data 1,20,21 6,7,8
60 4 Class 3 Data 1,20,21 6,7,8
70 1 File Identifier
80 1 Internal Indications 2
0,1
index = 7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
101 1 Small Packed Binary-Coded Decimal
101 2 Medium Packed Binary-Coded Decimal
101 3 Large Packed Binary-Coded Decimal
112 All Virtual Terminal Output Block 2 6
113 All Virtual Terminal Event Data 1,20,21 6 129,130 17,28
No object 13,14,23
