5-2 Metering and Monitoring Date Code 20080110
SEL-387E Instruction Manual
Note: If current or voltage transformers are connected delta (DELTA_Y = D, WnCT = D) or
only one voltage is connected (TPVI = N), only total power (MW, MVAR, MVA) will
display in the METER report. This restricted calculation assumes balanced load
conditions. Setting the current voltage winding setting (VIWDG) to 12 combines the
current in Winding 1 and Winding 2 and displays their sum in the METER report.
The format for the METER report is as follows:
=>>METER <Enter>
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
Phase Currents Sequence Currents
Wdg1 IAW1 IBW1 ICW1 3I1W1 3I2W1 IRW1
I (A,pri) 123 123 123 123 123 123
Wdg2 IAW2 IBW2 ICW2 3I1W2 3I2W2 IRW2
I (A,pri) 123 123 123 123 123 123
Wdg3 IAW3 IBW3 ICW3 3I1W3 3I2W3 IRW3
I (A,pri) 123 123 123 123 123 123
Wdg1&2 IAW12 IBW12 ICW12 IRW12
I (A,pri) 123 123 123 123
Phase Voltages Sequence Voltages
WdgX VAWX VBWX VCWX 3V1WX 3V2WX VRWX
V (KV,pri) 123.12 123.12 123.12 123.12 123.12 123.12
Power Quantities
MW MWA MWB MWC
P (MW,pri) 123.12 123.12 123.12 123.12
MVAR MVRA MVRB MVRC
Q (MVar,pri) 123.12 123.12 123.12 123.12
MVA MVAA MVAB MVAC
S (MVa,pri) 123.12 123.12 123.12 123.12
FREQ (Hz) 12.12
V/Hz (percent) 12.12
VDC (V) 123.1
=>>
Demand Ammeter Function (METER D Command)
The SEL-387E Relay includes a thermal demand metering function for all three current
windings. In response to the METER D (MET D) command, the individual phase demand
currents, as well as the negative-sequence and residual demand currents for each winding, are
displayed in primary RMS amperes. If the command is typed as MET D m, where m is any
number from 1 to 32767, the report will be repeated m times in succession. In this mode
subsequent reports are not generated until the previous report has been completely sent. The
format for the METER D report is as follows:
