Schweitzer Engineering Laboratories SEL-387E - SEL-387 E Relay SHO G (Show Global Settings)

Date Code 20080110 Settings 6-9
SEL-387E Instruction Manual
D EFAULT S ETTINGS
SEL-387E Relay SHO G (Show Global Settings)
=>>SHO G <Enter>
LER = 15 PRE = 4 NFREQ = 60 PHROT = ABC
DELTA_Y = Y
DATE_F = MDY SCROLD = 2 FP_TO = 16 TGR = 3
DC1P = OFF DC2P = OFF DC3P = OFF DC4P = OFF
BKMON1 =TRIP1 + TRIP4
B1COP1 = 10000 B1KAP1 = 1.2
B1COP2 = 160 B1KAP2 = 8.0
B1COP3 = 12 B1KAP3 = 20.0
BKMON2 =TRIP2 + TRIP4
B2COP1 = 10000 B2KAP1 = 1.2
B2COP2 = 160 B2KAP2 = 8.0
B2COP3 = 12 B2KAP3 = 20.0
BKMON3 =TRIP3 + TRIP4
B3COP1 = 10000 B3KAP1 = 1.2
B3COP2 = 160 B3KAP2 = 8.0
B3COP3 = 12 B3KAP3 = 20.0
ETHRU =N
IAW1 =IAW1
IBW1 =IBW1
ICW1 =ICW1
IAW2 =IAW2
IBW2 =IBW2
ICW2 =ICW2
IAW3 =IAW3
IBW3 =IBW3
ICW3 =ICW3
VAWX =VAWX
VBWX =VBWX
VCWX =VCWX
SS1 =0
SS2 =0
SS3 =0
SS4 =0
SS5 =0
SS6 =0
LEDA =OCA + 87E1
LEDB =OCB + 87E2
LEDC =OCC + 87E3
DP1 =IN101
DP1_1 =BREAKER 1 CLOSED DP1_0 =BREAKER 1 OPEN
DP2 =IN102
DP2_1 =BREAKER 2 CLOSED DP2_0 =BREAKER 2 OPEN
DP3 =IN103
DP3_1 =BREAKER 3 CLOSED DP3_0 =BREAKER 3 OPEN
DP4 =0
DP4_1 = DP4_0 =
DP5 =0
DP5_1 = DP5_0 =
DP6 =0
DP6_1 = DP6_0 =
DP7 =0
DP7_1 = DP7_0 =
DP8 =0
(continued on next page)
