SEL-387E Settings Sheets
Page 1 of 28
Group Settings (SET Command)
Date
Group
Date Code 20080110
C
ONFIGURATION
S
ETTINGS
Relay Identifier (39 Characters)
RID =
Terminal Identifier (59 Characters)
TID =
Enable Winding 1 in Differential Element (Y, N, Y1) E87W1 =
Enable Winding 2 in Differential Element (Y, N, Y1) E87W2 =
Enable Winding 3 in Differential Element (Y, N, Y1) E87W3 =
Enable Winding 1 O/C Elements and Dmd Thresholds (Y, N) EOC1 =
Enable Winding 2 O/C Elements and Dmd Thresholds (Y, N) EOC2 =
Enable Winding 3 O/C Elements and Dmd Thresholds (Y, N) EOC3 =
Enable Combined O/C Elements (Y, N) EOCC =
Enable Volts/Hertz Protection (Y, N) E24 =
Enable Undervoltage Protection (Y, N) E27 =
Enable Overvoltage Protection (Y, N) E59 =
Enable Frequency Protection (N, 1–6) E81 =
Enable SEL
OGIC
®
Control Equations Set 1 (Y, N) ESLS1 =
Enable SEL
OGIC
Control Equations Set 2 (Y, N) ESLS2 =
Enable SEL
OGIC
Control Equations Set 3 (Y, N) ESLS3 =
G
ENERAL
D
ATA
Winding 1 CT Connection (D, Y) W1CT =
Winding 2 CT Connection (D, Y) W2CT =
Winding 3 CT Connection (D, Y) W3CT =
Winding 1 CT Ratio (1–50000) CTR1 =
Winding 2 CT Ratio (1–50000) CTR2 =
Winding 3 CT Ratio (1–50000) CTR3 =
Maximum Power Transformer Capacity (OFF, 0.2–5000 MVA) MVA =
Define Internal CT Connection Compensation (Y, N) ICOM =
Winding 1 CT Conn. Compensation (0, 1, …, 12) W1CTC =
Winding 2 CT Conn. Compensation (0, 1, …, 12) W2CTC =
Winding 3 CT Conn. Compensation (0, 1, …, 12) W3CTC =
Winding 1 Line-to-Line Voltage (1–1000 kV) VWDG1 =
