Date Code 20080110 Control Logic 4-33
SEL-387E Instruction Manual
Row Bit Definition
23 * Reserved for future use
* Reserved for future use
* Reserved for future use
* Reserved for future use
* Reserved for future use
* Reserved for future use
DC3 DC battery voltage Level 3 exceeded
DC4 DC battery voltage Level 4 exceeded
24 RB1 Remote bit RB1 asserted
RB2 Remote bit RB2 asserted
RB3 Remote bit RB3 asserted
RB4 Remote bit RB4 asserted
RB5 Remote bit RB5 asserted
RB6 Remote bit RB6 asserted
RB7 Remote bit RB7 asserted
RB8 Remote bit RB8 asserted
25 RB9 Remote bit RB9 asserted
RB10 Remote bit RB10 asserted
RB11 Remote bit RB11 asserted
RB12 Remote bit RB12 asserted
RB13 Remote bit RB13 asserted
RB14 Remote bit RB14 asserted
RB15 Remote bit RB15 asserted
RB16 Remote bit RB16 asserted
26 SG1 Setting Group 1 is the active setting group
SG2 Setting Group 2 is the active setting group
SG3 Setting Group 3 is the active setting group
SG4 Setting Group 4 is the active setting group
SG5 Setting Group 5 is the active setting group
SG6 Setting Group 6 is the active setting group
CHSG Timing to change setting groups
* Reserved for future use
