4-44 Control Logic Date Code 20080110
SEL-387E Instruction Manual
Bit Definition Row
CF1T Breaker 1 close failure timer timed out 42
CF2T Breaker 2 close failure timer timed out 42
CF3T Breaker 3 close failure timer timed out 42
CHSG Timing to change setting groups 26
CLS1 Breaker 1 CLOSE output asserted 42
CLS2 Breaker 2 CLOSE output asserted 42
CLS3 Breaker 3 CLOSE output asserted 42
CTS Current transformer saturation 14
DC1 DC battery voltage Level 1 exceeded 22
DC2 DC battery voltage Level 2 exceeded 22
DC3 DC battery voltage Level 3 exceeded 23
DC4 DC battery voltage Level 4 exceeded 23
DCBL DC block asserted 27
IN101 Input IN101 asserted 27
IN102 Input IN102 asserted 27
IN103 Input IN103 asserted 27
IN104 Input IN104 asserted 27
IN105 Input IN105 asserted 27
IN106 Input IN106 asserted 27
IN201 Input IN201 asserted 28
IN202 Input IN202 asserted 28
IN203 Input IN203 asserted 28
IN204 Input IN204 asserted 28
IN205 Input IN205 asserted 28
IN206 Input IN206 asserted 28
IN207 Input IN207 asserted 28
IN208 Input IN208 asserted 28
IN209 Input IN209 asserted 29
IN210 Input IN210 asserted 29
IN211 Input IN211 asserted 29
IN212 Input IN212 asserted 29
IN213 Input IN213 asserted 29
IN214 Input IN214 asserted 29
IN215 Input IN215 asserted 29
IN216 Input IN216 asserted 29
IN301 Input IN301 asserted 30
IN302 Input IN302 asserted 30
IN303 Input IN303 asserted 30
