(continued from previous page)
VNOM = 230.00 24WDG = Y 24D1P = 105 24D1D = 1.00
24CCS = ID 24IP = 105 24IC = 2.0 24ITD = 0.1
24D2P2 = 176 24D2D2 = 3.00 24CR = 240.00
24TC =1
27P1P = 20.0 27P2P = 0.0
27PP1 = 35.0 27PP2 = 0.0 27V1P = 0.0
59P1P = 74.0 59P2P = OFF
59G1P = 20.0 59G2P = OFF 59QP = OFF
59PP1 = 128.0 59PP2 = OFF 59V1P = OFF
TDURD = 9.000 CFD = 60.000
TR1 =50P11T + 51P1T + 51Q1T + OC1 + LB3
TR2 =51P2T + 51Q2T + OC2
TR3 =50P31 + 51P3T + OC3
TR4 =87R + 87U
ULTR1 =!50P13
ULTR2 =!50P23
ULTR3 =!50P33
ULTR4 =!(50P13 + 50P23 + 50P33)
52A1 =IN101
52A2 =IN102
52A3 =IN103
CL1 =CC1 + LB4 + /IN104
CL2 =CC2 + /IN105
CL3 =CC3 + /IN106
ULCL1 =TRIP1 + TRIP4
ULCL2 =TRIP2 + TRIP4
ULCL3 =TRIP3 + TRIP4
ER =/50P11 + /51P1 + /51Q1 + /51P2 + /51Q2 + /51P3
OUT101 =TRIP1
OUT102 =TRIP2
OUT103 =TRIP3
OUT104 =TRIP4
OUT105 =CLS1
OUT106 =CLS2
OUT107 =CLS3
OUT201 =0
OUT202 =0
OUT203 =0
OUT204 =0
OUT205 =0
OUT206 =0
OUT207 =0
OUT208 =0
OUT209 =0
OUT210 =0
OUT211 =0
OUT212 =0
SCEUSE 47.8
GR1CHK 68EB
=>>
Note: SCEUSE is the percent of SEL OGIC control equations used in this setting group.
GRnCHK is the Group setting checksum used by the relay's diagnostics.
