SEL-387E Relay Settings Sheet
Page 25 of 28
Sequential Events Recorder Settings
Date
(SET R Command) Example
Date Code 20080110
T
RIGGER
C
ONDITIONS
Trigger SER (24 Relay Word bits per SERn equation, 96 total)
SER1 = IN101 IN102 IN103 IN104 IN105 IN106
SER2 = OUT101 OUT102 OUT103 OUT104 OUT105 OUT106 OUT107
SER3 = 0
SER4 = 0
R
ELAY
W
ORD
B
IT
A
LIASES
Syntax: ‘Relay-Word Bit’ ‘Up to 15 characters’. Use NA to disable setting.
ALIAS1 = NA
ALIAS2 = NA
ALIAS3 = NA
ALIAS4 = NA
ALIAS5 = NA
ALIAS6 = NA
ALIAS7 = NA
ALIAS8 = NA
ALIAS9 = NA
ALIAS10 = NA
ALIAS11 = NA
ALIAS12 = NA
ALIAS13 = NA
ALIAS14 = NA
ALIAS15 = NA
ALIAS16 = NA
ALIAS17 = NA
ALIAS18 = NA
ALIAS19 = NA
ALIAS20 = NA
To Next Page
