SEL-387E Relay Settings Sheet Page 27 of 28
Port Settings (SET P Command) Example Date
Date Code 20080110
Enable hardware handshaking (Y, N) RTSCTS = N
Fast Operate Enable (Y, N) FASTOP = N
P ORT 3 (SET P 3) R EAR P ANEL , EIA-232
Port Protocol (SEL, LMD, DNP) PROTO = SEL
LMD Prefix (@, #, $, %, &) PREFIX =
LMD Address (1–99) ADDR =
LMD Settling Time (0–30 seconds) SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED = 2400
Data Bits (7, 8) BITS = 8
Parity Odd, Even, or None (O, E, N) PARITY = N
Stop Bits (1, 2) STOP = 1
Time-out (for inactivity) (0–30 minutes) T_OUT = 5
Send auto messages to port (Y, N) AUTO = N
Enable hardware handshaking (Y, N) RTSCTS = N
Fast Operate Enable (Y, N) FASTOP = N
P ORT 4 (SET P 4) F RONT P ANEL , EIA-232
Port Protocol (SEL, LMD, DNP) PROTO = SEL
LMD Prefix (@, #, $, %, &) PREFIX =
LMD Address (1–99) ADDR =
LMD Settling Time (0–30 seconds) SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED = 2400
Data Bits (7, 8) BITS = 8
Parity Odd, Even, or None (O, E, N) PARITY = N
Stop Bits (1, 2) STOP = 1
Time-out (for inactivity) (0–30 minutes) T_OUT = 5
Send auto messages to port (Y, N) AUTO = N
Enable hardware handshaking (Y, N) RTSCTS = N
Fast Operate Enable (Y, N) FASTOP = N
