Date Code 20080110 Communications 7-13
SEL-387E Instruction Manual
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
Active Group = N
=>>
• RID and TID settings for the new active group
• Date and time of group change
• Active setting group now being used
Note: The SET G settings SS1 through SS6 take precedence over the GRO n command.
Relay Self-Test Warning or Failure
The relay automatically generates a status report whenever the self-tests declare a failure state
and some warning states.
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
FID=SEL-387E-R700-V0-Z101003-D20060616
SELF TESTS
W=Warn F=Fail
IAW1 IBW1 ICW1 IAW2 IBW2 ICW2
OS 123 123 123 123 123 123
IAW3 IBW3 ICW3 VAWX VBWX VCWX
OS 123 123 123 123 123 123
+5V_PS +5V_REG -5V_REG +12V_PS -12V_PS +15V_PS -15V_PS
PS 1.12 1.12 -1.12 12.12 -12.12 12.12 -12.12
TEMP RAM ROM A/D CR_RAM EEPROM IO_BRD
MB 26.0 OK OK OK OK OK OK
RAM ROM PORT 5 PORT 6 FPGA BOARD DPRAM PS
CC N/A N/A N/A N/A N/A FAIL N/A N/A
Relay Enabled
=>>
• RID and TID settings for the active group
• Date and time the failure or warning was detected
• Firmware identification string
• Individual self-test results
• Relay protection enabled or disabled indication
Event Summary Message
An automatic message is generated each time an event is triggered. The message is a summary
of the event.
