7-18 Communications Date Code 20080110
SEL-387E Instruction Manual
BAC (Access Level B)
Access Levels 1, 2
Use the BAC command to enter Access Level B. The default password for Level B is shown in
the table under PAS (Passwords) later in this section. Use the PAS command from Access
Level 2 to change this password. Install main board jumper JMP6A to disable password
protection.
The following display indicates successful access to Level B:
=>BAC <Enter>
Password: ? @@@@@ <Enter>
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
Breaker Level
==>
The relay pulses the ALARM contact closed for one second after any Level B access attempt,
unless an alarm condition already exists.
BRE (Breaker Report)
Access Levels 1, B, 2
Use the BRE command to display a report of breaker operation information. The breaker report
provides trip counter and trip current information for up to three breakers. The summary of the
operations provides valuable breaker diagnostic information at a glance. An example breaker
report follows. Refer to Section 5: Metering and Monitoring for further information. If the
Analog Input Label settings (IAW1, etc.) have been renamed, these will appear in the report as
set.
=>>BRE <Enter>
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
BREAKER 1
Int Trips= 12345 IAW1= 12345 IBW1= 12345 ICW1= 12345 kA(pri)
Ext Trips= 12345 IAW1= 12345 IBW1= 12345 ICW1= 12345 kA(pri)
Percent Wear: POLE1= 123 POLE2= 123 POLE3= 123
BREAKER 2
Int Trips= 12345 IAW2= 12345 IBW2= 12345 ICW2= 12345 kA(pri)
Ext Trips= 12345 IAW2= 12345 IBW2= 12345 ICW2= 12345 kA(pri)
Percent Wear: POLE1= 123 POLE2= 123 POLE3= 123
BREAKER 3
Int Trips= 12345 IAW3= 12345 IBW1= 12345 ICW3= 12345 kA(pri)
Ext Trips= 12345 IAW3= 12345 IBW1= 12345 ICW3= 12345 kA(pri)
Percent Wear: POLE1= 123 POLE2= 123 POLE3= 123
LAST BREAKER MONITOR RESET FOR Bkr1: MM/DD/YY HH:MM:SS.SSS
Bkr2: MM/DD/YY HH:MM:SS.SSS
Bkr3: MM/DD/YY HH:MM:SS.SSS
=>>
