W1 W2 W3 V CMBO
DIF DC F PWR ENG
System Frequency
FREQ= 12.12
VAWX= 123.1
(V,sec)= 123.12˚
VAWX= 123.12 kV
VBWX= 123.12 kV
V: METER
INST SEC
VBWX= 123.1
(V,sec)= 123.12˚
VCWX= 123.1
(V,sec)= 123.12˚
3V1WX= 123.1
(V,sec)= 123.12˚
3V2WX= 123.1
(V,sec)= 123.12˚
VRWX= 123.1
(V,sec)= 123.12˚
VCWX= 123.12 kV
3V1WX= 123.12 kV
3V2WX= 123.12 kV
VRWX= 123.12 kV
Figure 8.6: METER Menu and Display Structure (
continued)
