Date Code 20080110 Analyzing Events 9-9
SEL-387E Instruction Manual
=>>EVE D <Enter>
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
FID=SEL-387E-R700-V0-Z101003-D20060616
Overcurrent Elements Voltage/Freq
Winding 1 Winding 2 Winding 3 Elements D
5 5 5 5 5 5 5 2 2 5 8 T E O
0 1 0 1 0 1 1 4 7 9 1 R D M U I
PPABCNNQQPNQ PPABCNNQQPNQ PPABCNNQQPNQ PN DC PVPPVPGQ P C PPNNQQ T N
123331212 123331212 123331212 CC 12 1P 1P 135 13 13 131313 1357 135
444 444 444 11 246 24 24 2 2 2 246A 246
[1]
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
[2]
............ ............ ............ .. .. ........... .. .. ...... .... ...>
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...*
.
.
.
[15]
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
............ ............ ............ .. .. ........... .. .. ...... .... ...
Event: TRIP1 TRIP2 TRIP3 TRIP4
Targets: TRIP INST 87-1 87-2 87-3 24 81 A B C N W1 W2 W3 50/51
Winding 1 Currents (A Sec), ABC: 123.1 123.1 123.1
Winding 2 Currents (A Sec), ABC: 123.1 123.1 123.1
Winding 3 Currents (A Sec), ABC: 123.1 123.1 123.1
Winding X Voltages (V Sec), ABC: 123.1 123.1 123.1
Volts/Hertz Percent: 123.1
=>>
Figure 9.3: Example Digital Event Report
The trigger row includes a ‘>’ character following immediately after the last digital column to
indicate the trigger point. A ‘*’ character following immediately after the last digital column
denotes that the designated row was used for the Event Summary currents. The ‘*’ character
takes precedence over the ‘>’ character when both conditions occur for the same row.
The following table summarizes the digital event report columns.
