Date Code 20080110 Configuration, Fast Meter, and Fast Operate Commands D-7
SEL-387E Instruction Manual
0000
494157330000 (IAW3)
02
FF
0000
494257330000 (IBW3)
02
FF
0000
494357330000 (ICW3)
02
FF
0000
334932573300 (3I2W3)
02
FF
0000
495257330000 (IRW3)
02
FF
0000
1-byte Reserved
1-byte Checksum
A5D2/A5D3 Demand/Peak Demand
Fast Meter Message
In response to the A5D2 or A5D3 request, the relay sends the following block:
Data
Description
A5D2 or A5D3 Command
7E Message length (126 bytes)
1-byte Reserved
120-bytes Demand meter values in double floats in the same order as channel
listings in A5C2.
1-byte Reserved
1-byte Checksum
A5CE
Fast Operate Configuration Block
In response to the A5CE request, the relay sends the following block:
Data
Description
A5CE Command
40 Message length, #bytes (64)
03 # circuit breakers supported
0010 16 remote bits
01 Remote bit pulse supported
00 Reserved
31 Open breaker 1
11 Close breaker 1
