0F Clear remote bit RB16
2F Set remote bit RB16
4F Pulse remote bit RB16
1-byte Reserved
1-byte Checksum
A5E0
Fast Operate Remote Bit Control
The external device sends the following message to perform a remote bit operation (set, clear,
pulse):
Data
Description
A5E0 Command
06 Message length
1-byte Operate code (0-F, 20-2F, 40-4F for remote bit clear, set or pulse)
1-byte Operate validation: 4 * operate code + 1
1-byte Checksum
Remote bit set and clear operations are latched by the relay. Remote bit pulse operations assert
the remote bit for one processing interval.
A5E3
Fast Operate Breaker Control
The external device sends the following message to perform a fast breaker open/close of
breakers 1 through 4:
Data
Description
A5E3 Command
06 Message length
1-byte Operate code (hex 31–33 open, hex 11–13 close breakers 1 through 3)
1-byte Operate validation: 4 * operate code + 1
1-byte Checksum
A5CD
Fast Operate Reset Definition Block
In response to an A5CD request, the relay sends the configuration block for the Fast Operate
Reset message
Data
Description
A5CD Command
0E Message length
01 The number of Fast Operate reset codes supported
1-byte Reserved for future use
Per Fast Operate reset code, repeat:
00 Fast Operate reset code (e.g., "00" for target reset)
54415220520000 Fast Operate reset description string (e.g., "TAR R")
1-byte Checksum
