F-4 Unsolicited SER Protocol Date Code 20080110
SEL-387E Instruction Manual
0000000000 Five bytes reserved for future use as a routing address
YY Status Byte (01 = need acknowledgment; 03 = settings changed and need
acknowledgment)
18 Function code
C0 Sequence byte (Always C0. Other values are reserved for future use in
multiple frame messages.)
XX Response number (XX = 00, 01, 02, 03, 01, 02...)
00000000 Four bytes reserved for future use as a return routing address
dddd Two-byte day of year (1–366)
yyyy Two-byte, four-digit year (e.g., 1999 or 07CF hex)
mmmmmmmm Four-byte time of day in milliseconds since midnight
XX 1st element index (match with the response to the SNS command; 00 for 1st
element, 01 for second element, and so on)
uuuuuu Three-byte time tag offset of 1st element in microseconds since time indicated
in the time of day field.
XX 2nd element index
uuuuuu Three-byte time tag offset of 2nd element in microseconds since time
indicated in the time of day field.
.
.
.
xx last element index
uuuuuu Three-byte time tag offset of last element in microseconds since time indicated
in the time of day field.
FFFFFFFE Four-byte end-of-records flag
ssssssss Packed four-byte element status for up to 32 elements (LSB for the 1st
element)
cccc Two-byte CRC-16 checkcode for message
If the relay determines that SER records have been lost, it sends a message with the following
format:
Data
Description
A546 Message header
22 Message length (34 decimal)
0000000000 Five bytes reserved for future use as a routing address.
YY Status Byte (01 = need acknowledgment; 03 = settings changed and need
acknowledgment)
18 Function code
C0 Sequence byte (Always C0. Other values are reserved for future use in
multiple frame messages.)
XX Response number (XX = 00, 01, 02, 03, 00, 01, ...)
00000000 Four bytes reserved for future use as a return routing address
dddd Two-byte day of year (1–366) of overflow message generation
yyyy Two-byte, four-digit year (e.g., 1999 or 07CF hex) of overflow message
generation.
mmmmmmmm Four-byte time of day in milliseconds since midnight
FFFFFFFE Four-byte end-of-records flag
