Sensia JISKOOT InSpec Sampler User Manual

InSpec Sampler Controller SECTION 24: FIELD CONNECTIONS
101
Figure 55 - Voltage and Current Pulse Signals
10k
10
9
-
+
0
0
0
0
0-24V
270R
AC
10k
10
9
-
+
0
0
0
0
270R
AC
4-20mA
Figure 56 - Connecting a Voltage or Current Pulse Input
24.4.4 4-20mA ANALOGUE OUTPUT (2 off)
Each analogue output is a current source, sometimes referred to as a ‘powered’ or ‘active’
output.
14
13
-
+
250R
(1-5V)
4-20mA
Figure 57 - Connecting an Analogue Output
24.4.5 4-20mA ANALOGUE INPUT (3 off)
Each analogue input has a ‘passive’ differential input type.
50R
20
19
-
+
0
0
0
0
4-20mA
DC
Supply
50R
20
19
0
0
0
0
OR
Tx
Figure 58 - Connecting an Analogue Input
Voltage Pulse Signal
-0.5
4.5
9.5
14.5
19.5
24.5
Time
Volts
Input Signal Threshold
Current Pulse Signal
-0.5
4.5
9.5
14.5
19.5
24.5
Time
mA
Input Signal Threshold
