Sensia JISKOOT InSpec Sampler User Manual

InSpec Sampler Controller SECTION 25: INSTRUMENT SPECIFICATIONS
103
Accuracy
±0.1% of FSD (12-bit resolution)
Output Protection
Over Voltage (26VDC TVS)
Analogue Inputs
Quantity
3
Input Type
4-20mA
Accuracy
±0.1% of FSD (12-bit resolution)
Input Impedance
50 ohms
Input Protection
Over Voltage (26VDC TVS)
Pulse Inputs
Quantity
2
Input Type
0 - 24V DC Voltage Pulse or
4 – 20mA DC Current Pulse
Max. Frequency 10kHz
Accuracy
± 1 count in any given sampling period
Input Impedance
10 k ohms - Voltage input
263 ohms - Current input
Adj. Trig Threshold Range
Approx. 2.2 to 24 V DC (8 to 20mA DC)
Input Protection
Over & Reverse Voltage (26VDC TVS)
Communications
Quantity
3 (User Ports) + 2 (System Ports)
Type
2 off configurable RS232/422/485 ports.
1 off Ethernet port.
Input Protection
Over Voltage (26VDC TVS)
25.2 INSULATION CO-ORDINATION
25.2.1 AC POWER INLET CREEPAGE/CLEARANCE
Creepage / Clearance from PE to Live or Neutral
 3 / 3 mm
25.2.2 RELAY OUTPUTS CREEPAGE/CLEARANCE
Creepage / Clearance from Coil to Contact Circuits
 8 / 8 mm
Creepage / Clearance between Relay Circuits
 6 / 6 mm
25.3 COMPLIANCE TO INTERNATIONAL STANDARDS
EN 61010-1
IEC 61010-1
UL 61010-1
CAN/CSA-C22.2 No. 61010-1
Safety requirements for electrical equipment for
measurement, control, and laboratory use – Part 1:
General requirements.
EN 61326
Electrical equipment for measurement, control and
laboratory use – EMC requirements.
FCC CFR47 Part 15
Radio Frequency Devices.
